Advanced High Efficient Customized Industrial Cyclone Separator for
Industry
What is industrial cyclone separator?
Cyclone separator is a device used for separating gas-solid system
or liquid-solid system.
The working principle is that the solid particles or droplets with
large inertia centrifugal force are separated from the outer wall
surface by the rotation motion caused by tangential introduction of
air flow.
The main characteristic of cyclone separator is simple in structure
and large elasticity of operation, high efficiency, convenient
management and maintenance, low cost, is used to capture dust above
5 ~ 10 microns in diameter, are widely used in the pharmaceutical
industry, especially suitable for dust particles coarser, dust
concentration is larger, high temperature and high pressure
conditions, also often used as a fluidized bed reactor of
separation device, or used as pre separator, is a kind of industry
application is very wide separation equipment.
What are the features of industrial cyclone separator?
- The pressures and temperatures that headers have to withstand
depend on the component to which they are connected. A header
connected to an economizer or to water wall panels is subject to
less severe requirements on the material than a header connected to
superheaters or reheaters.
- Depending on the temperature and pressure of headers, Vallourec
supplies tubes in carbon steel to high-alloy ferritic steels such
as T/P91 or T/P92, with sizes ranging from 88.9 mm to 406.4 mm.
What are the functions of industrial cyclone separator?
1.Enhance Heat Transfer
The air after the heat exchanger enters the furnace, which
accelerates the drying, ignition and combustion process of the
fuel, ensures the stable combustion in the boiler and improves the
combustion efficiency.
2. Improve and intensify combustion
Because the combustion in the furnace has been improved and
strengthened, and the temperature of hot air entering the furnace
has been increased, the average temperature level in the furnace
has also been raised, so the radiation heat transfer in the furnace
can be strengthened.
3. Hot air can be used as fuel desiccant.
Because of the stable combustion in the furnace and the enhanced
radiation heat exchange, the chemical incomplete combustion loss
can be reduced. On the other hand, the air preheater uses the waste
heat of flue gas to further reduce the loss of exhaust gas, thus
improving the thermal efficiency of the boiler. According to
experience, when the air in the preheater rises by 1.5 C, the
exhaust gas temperature can be reduced by 1 C. After installing the
air preheater in the boiler flue, if the air waste heat can be
150-160 C, the exhaust gas temperature can be reduced by 110-120 C,
and the thermal efficiency of the boiler can be increased by
7%-7.5%. Fuel can be saved by 11%-12%.
4. Reducing the loss in the furnace, lowering the exhaust gas
temperature and improving the thermal efficiency of the boiler.
Hot air is an important desiccant and pulverized coal conveying
medium for grease powder system in power plant boilers.
What are the parameters of industrial cyclone separator?
| Material | Carbon steel,Alloy steel,Stainless steel. |
| Length | According to costumes requirements. |
| Temperature Range | 300℃~1500℃ |
| Diameter(OD) | 76mm~914mm |
What is the working principle of industrial cyclone separator?
Cyclone separator is a kind of dry gas-solid separation equipment
which can separate dust from air stream by using centrifugal force
generated by gas-solid mixture when rotating at high speed.
The separation efficiency is higher because the centrifugal force
is much higher than the gravity and inertia force.
